JGMaker A5S 3D Printer Kit Metal Frame Touch Screen 305x305x320 Print Size

This item ships from our: UK Warehouse
Ships to UK only.
Other destinations: Please contact us for details.

Product description

The JGMaker A5S builds upon the success of the A5 model with plenty of updates based on customers feedback. It’s now one of only a handful of 3D printers in this price bracket that offer a print volume this large, Ideal if you’re looking to print large objects like cosplay armour or tabletop terrain/buildings. Featuring a large 305 x 305 x 320 mm print volume that rivals the Creality CR-10, but thanks to the clever integrated PSU occupies a smaller footprint.

The A5S has a heated borosilicate glass bed with an additional ‘black diamond’ coating, this provides an excellent surface for your models to grip to. The A5S has assisted bed levelling which helps position the extruder for you to perform the 'paper width' test. Driving the A5S is a new 32-bit mainboard to control the Allegro A5984 silent stepper motors, these provide 32x micro stepping levels and numerous safety features including thermal runaway protection. This update allows the printer to achieve faster speeds and low power consumption.

Due to new import laws, this product no longer contains an SD Card/USB Drive, please visit our A5S download page for the latest drivers and software.



  • Light industry main body design, terseness and not lack of novelty.
  • Large build size: 305×305×320mm, with assistant levelling system.
  • Self-patent Black Diamond Grass platform: allows easy removal of the platform and the printed parts and a cleaner appearance.
  • Unique gap less feeding system, load filament smoothly, print excellent models.
  • Intellective large touch screen control: provides better 3D printing user experience. semi-automatic levelling control.
  • Power failure protection: resume print from where the last print is stopped due to power failure.
  • The automatic material recognition system saves time and effort with material information and print profiles preloaded on each reel to let you start printing straight away. And extruder will be stop heating up if no new filament feeding after one hour.
  • Better customer experience, high print accuracy and high speed with quiet working, suit for school and home.
  • Famous power supply from MW with CE, UL certificate.
  • Solid structure: Using CNC sheet metal cutting craft, it will keep printing process stably, which effectively guarantees smooth printing of the model
  • Filament Run-Out Detection: In the event of your filament running out too soon, A5S will detect this and pause your print so you can fit a new spool of filament and resume the print, saving you from failed print disaster!
  • 32-bit motherboard: Using Allegro A5984 stepper drivers with 32x micro stepping.
  • Patented nozzle structure: High-precision independent patent nozzle design that will prevent clogging effectively.
  • Dual Z lead screw: It decreases the likelihood of print errors, and improving accuracy and precision, resulting in a specified Z-axis accuracy of 0.001mm. add a 'pro' level to the printer.
  • SD card removed accidentally: For any reason happen to remove the SD Card during the printing, you can continue printing by reinserting the SD card.

Brand: JGMaker
Type: Metal,Complete Machine,CNC
Model: A5S
Platform material: Aluminum Alloy + black diamond glass
Nozzle quantity: Single
Nozzle diameter: 0.4mm
Nozzle temperature: Room temperature to 245 degree
Product forming size: 305×305×320mm
Layer thickness: 0.05-0.3mm
Memory card offline print: Sd Card
LCD Screen: Yes
Print speed: 10-120mm/s(Suggest 30-60mm/s)
Platform temperature: Room temperature to 105 degree
Material diameter: 1.75mm
Language: English,French,
File format: BMP,JPG,STL,G-code,OBJ
Model supporting function: Yes
XY-axis positioning accuracy: 0.011mm
Z-axis positioning accuracy: 0.0025mm
Voltage: 110-240V
Working Power: 300W
Host computer software: Repetier-Host,Cura,Slic3r
Packing type: Assembled packing
System support: Windows7/8/Windows10/XP, Mac, Linux
Voltage Range: AC 110-220V
Certificate: CE, RoHs,FCC, ISO9001-2015, Test report
Package Includes: 1x Fully-assembled JGMaker A5S
1x PLA 1.75 White 0.25KG/spool
1x Warranty Card
1x USB cable (1.5m) 1x 1.5mm Allen wrench
1x 2.0mm Allen wrench, 1x power cable.
